SN-WDZX-200L;SN-WDZX-300L
scienovo
ISO9001/CE
2 Years
OEM Service
| Quantity: | |
|---|---|
Product Features |
Intelligent microcomputer control system: Using LED digital control system; After sterilization finished, sterilizer will automatic alarm and shut down.
Interlock device： The control system can real time supervision the sterilizer chamber's temperature and pressure. Only under the safety temperature and pressure can open the sterilizer's cover. Make sure the operators safety.
The structure of cover's opening: Using8 rotary extendable stick to improve sealing and safety performance.
Preset program： Can preset fixed program that sterilize solid body.
Memory storage system： Store the Last operation program so convenient next operation.
Exhaust Steam control ： After sterilization, exhaust steam valve should be opened (Digital display screen reminds exhaust steam) when sterilization time run out Interface check： provide temperature and pressure check interface; convenient to check multiple position temperature measurement.
Digital display screen： Digital display screen and working indicator Light display running state.
Safety devices： Interlock device, overtemperature and over pressure protecting system, burned protection, safety relief valve, current Leakage protector and automatic fault detection.
Print function： Print the current temperature and sterilization time.
Technical Parameter |
Product Model | SN-WDZX-200L | SN-WDZX-300L |
Non-medical | Non-medical | |
Configuration | Semi-automatic control | Semi-automatic control |
The main material | Stainless steel | Stainless steel |
Volume/GW | 200L/300Kg | 300L/330Kg |
Voltage / Power | 380V/3.0KWx3 | 380V/4.0KWx3 |
Packing size (LxWxH mm) | 1640x830x1800 | 1640x930x1900 |
Product Size (LXWXHmm) | 1550x720x1640 | 1550x820x1740 |
Sterilization chamber volume (D X H mm) | 500X1120 | 600X1240 |
Basket Size ( Upper length x Upper width x Lower length x Lower width x Heigt mm) | 480x440x480x250x195 | 500x540x500x300x230 |
Time setting range | 0-99 h | 0-99 h |
Rated working pressure | 0.217MPa | 0.217MPa |
Sterilization temperature setting range | 50〜134°C | 50~134°C |
